东莞市霖钢包装机械设备有限公司

功能特点

1.本机适合OPP、PVC、PET、美纹胶带、双面胶带、泡棉胶带、布基胶带、电工胶带、纳米胶带等高分子材料膜分切之用.

2.智能10寸触摸屏及键式均可同时控制，操作简单.

3.双轴自动换转；双轴双刀同时分切，替换另两轴不停机卸成品及穿原材料，节省时间.

4.主轴转速调整、宽度设定、圆刀转速调整、切卷数设定、切刀延时设定、移位元速度、角度调整、寸动速度、到位延时.

5.矽溶液冷却系统：避免切刀沾胶，确保切管作业顺畅.

6.切管稳定性高：切刀采用伺服马达控制并可以根据不同的材质要求，调整切刀速度以达到高品质、高速度之切割.

7.主传动机构，同步皮带轮.

8.切刀：寿命长，刀头可调整，切刀可正逆转.

9.伺服马达驱动，配合精密螺杆及直线滑轨，使切刀行程顺畅，定位精确，伺服马达的精度为±0.2mm.

10.步进马达配合圆刀角度调整.

Functional Features

1. This machine is suitable for OPP PVC、PET、 Used for cutting polymer material films such as masking tape, double-sided tape, foam tape, cloth tape, electrical tape, nano tape, etc

2. The intelligent 10 inch touch screen and key type can be controlled simultaneously, with simple operation

3. Dual axis automatic rotation; Double axis dual blade simultaneous cutting, replacing the other two axes without stopping to unload finished products and thread raw materials, saving time

4. Spindle speed adjustment, width setting, circular cutter speed adjustment, roll cutting number setting, cutter delay setting, displacement element speed, angle adjustment, inch speed, and positioning delay

5. Silicon solution cooling system: Avoid sticking the cutting blade to the glue to ensure smooth pipe cutting operation

6. High stability of pipe cutting: The cutting blade is controlled by a servo motor and can adjust the cutting speed according to different material requirements to achieve high-quality and high-speed cutting

7. Main transmission mechanism, synchronous pulley

8. Cutting blade: Long lifespan, adjustable blade head, and reversible cutting blade

9. Driven by a servo motor, coupled with precision screws and linear slides, the cutting tool has a smooth stroke and precise positioning. The accuracy of the servo motor is ± 0.2mm

10. Adjust the angle of the stepper motor in conjunction with the circular blade
