| Main technical parameters | ||
| 有效裁切面宽 | Effective cutting surface width | 1300mm/1600mm |
| 切割宽度 | Cutting width | 2mm～1350mm |
| 切割纸心内径 | Cutting paper core inner diameter | 3-inch core (φ25-76.5mm) |
| 圆刀最大直径 | Maximum diameter of circular knife | φ450mm |
| 切割最大直径 | Cutting maximum diameter | φ350mm |
| 切割速度 | Cutting speed | 2-10秒/次 seconds/time |
| 使用气源 | air source | 6kw/cm² |
| 整机功率 | Whole machine power | About 7.5KW |
| 电源电压 | supply voltage | Three phase 380V/50HZ |
| 机身重量 | Weight | 1600KG |
1.本机适合OPP、PVC、PET、美纹胶带、双面胶带、泡棉胶带、布基胶带、电工胶带、纳米胶带等高分子材料膜分切之用.
2.智能10寸触摸屏及键式均可同时控制，操作简单.
3.主轴转速调整、宽度设定、圆刀转速调整、切卷数设定、切刀延时设定、移位元速度、角度调整、寸动速度、到位延时.
4.矽溶液冷却系统：避免切刀沾胶，确保切管作业顺畅.
5.切割稳定性高：切刀采用伺服马达控制并可以根据不同的材质要求，调整切刀速度以达到高品质、高速度之切割.
6.主传动机构，同步皮带轮.
7.切刀：寿命长，刀头可调整，切刀可正逆转.
8.伺服马达驱动，配合精密螺杆及直线滑轨，使切刀行程顺畅，定位精确，伺服马达的精度为±0.2mm.
9.步进马达配合圆刀角度调整.
1. This machine is suitable for OPP PVC、PET、 Used for cutting polymer material films such as masking tape, double-sided tape, foam tape, cloth tape, electrical tape, nano tape, etc
2. The intelligent 10 inch touch screen and key type can be controlled simultaneously, with simple operation
3. Spindle speed adjustment, width setting, circular cutter speed adjustment, roll cutting number setting, cutter delay setting, displacement element speed, angle adjustment, inch speed, and positioning delay
4. Silicon solution cooling system: Avoid sticking the cutting blade to the glue to ensure smooth pipe cutting operation
5. High cutting stability: The cutting blade is controlled by a servo motor and can adjust the cutting speed according to different material requirements to achieve high-quality and high-speed cutting
6. Main transmission mechanism, synchronous pulley
7. Cutting blade: Long lifespan, adjustable blade head, and reversible cutting blade
8. Driven by a servo motor, coupled with precision screws and linear slides, the cutting tool travel is smooth and the positioning is precise. The accuracy of the servo motor is ± 0.2mm
9. Adjust the angle of the stepper motor in conjunction with the circular blade
