| Main technical parameters | ||
| 最大原料宽度 | Maximum raw material width | 1300mm/1600mm |
| 最大原料直径 | Maximum cutting thickness | φ800mm |
| 最大收卷直径 | Minimum cutting width | φ450mm |
| 机械最高速度 | Mechanical maximum speed | 150m/min |
| 纸管内径 | Paper tube diameter | 3-inch core (φ76-76.5mm) |
| 使用气源 | air source | 6kw/cm² |
| 整机功率 | Whole machine power | About 10KW |
| 电源电压 | supply voltage | Three phase 380V/50HZ |
| 机身重量 | Weight | 2200KG |
1.用于离形纸、PET、双面胶带等基材贴合分切之用.
2.中心卷取方式.
3.卸料轴采用10KG磁粉式刹车；采用全自动制卸卷张力.
4.贴合分切采用 5.5 KW智马变频马达控制调速.
5.贴合分切采用 上下圆刀分切.
6.收卷采用 4KW智马 PG变频马达控制调速.
7.收卷轴可正反转卷取方向.
8.设计结构便于操作，维护保养简单、安全.
9.智能10寸触摸屏及键式均可同时控制.
1. Used for release paper PET、 Used for bonding and cutting substrates such as double-sided tape
2. Central winding method
3. The unloading shaft adopts 10KG magnetic powder brake; Adopting fully automatic unwinding tension
4. The fitting and cutting are controlled by a 5.5 KW Zhima variable frequency motor for speed regulation
5. The fitting and cutting are done using upper and lower circular knives
6. The winding is controlled by a 4KW Zhima PG variable frequency motor for speed regulation
7. The winding shaft can be rotated in both forward and reverse directions
8. The design structure is easy to operate, with simple and safe maintenance
9. The intelligent 10 inch touch screen and keyboard can be controlled simultaneously
