| Main technical parameters | ||
| 最大原料宽度 | Maximum raw material width | 1000mm/1300mm/1600mm |
| 最大原料直径 | Maximum raw material diameter | 800mm |
| 最大收卷直径 | Maximum winding diameter | φ170mm (four axis exchange) |
| 最大收卷直径 | Maximum winding diameter | φ310mm (dual axis exchange) |
| 最小分条宽度 | Minimum stripe width | 12mm |
| 分条方式 | Splitting method | 3-hole straight knife |
| 机械最高速度 | Mechanical maximum speed | 180m-260m/minute |
| 纸管内径 | Inner diameter of paper tube | 3-inch core (φ76-76.5mm) |
| 使用气源 | air source | 6kw/cm² |
| 整机功率 | Whole machine power | About 4.0KW |
| 电源电压 | supply voltage | Three phase 380V/50HZ |
| 机身重量 | Weight of the airframe | 1500KG |
1.用于Bopp印刷胶带分切之用。
2.放卷张力采用半自动张力控制器。
3.停机手动贴标，四轴自动交换上下停机换取轴。
4.采用压花特弗龙作主传动机构，惰轮采用阳极处理铝轮。
5.放卷采用10KG磁粉刹车。
6.分切刀架自动升降。
7.放卷采用气涨轴，方便放卷半成品的卸料和装料。
8.自动记米功能，到达设定米数长度自动减速停机，减少材料浪费。
9.主机自动变频控制，传动部分采用链轮传动。
10.移动罗拉缠绕式收边大卷废料。
1.Used for cutting Bopp printing tape.
2.The unwinding tension adopts a semi-automatic tension controller.
3.Shutdown manual labeling, automatic exchange of four axes up and down shutdown for axis exchange.
4.The embossed Teflon is used as the main transmission mechanism, and the idler wheel is made of anodized aluminum.
5.The unwinding adopts 10KG magnetic powder brake.
6.The slitting knife holder is automatically raised and lowered.
7.The unwinding adopts an air expanding shaft, which facilitates the unloading and loading of semi-finished products.
8.Automatic rice counting function, automatically decelerates and stops when reaching the set length of meters, reducing material waste.
9.The host adopts automatic frequency conversion control, and the transmission part adopts chain wheel drive.
10.Mobile roller winding edge trimming large roll waste.
