| Main technical parameters | ||
| 最大原料宽度 | Maximum raw material width | 1300mm/1600mm |
| 最大原料直径 | Maximum raw material diameter | φ800mm |
| 最大收卷直径 | Maximum winding diameter | φ350mm |
| 机械最高速度 | Mechanical maximum speed | 180m/min |
| 纸管内径 | Paper tube diameter | 3-inch core (φ25-76.5mm) |
| 使用气源 | air source | 6kw/cm² |
| 整机功率 | Whole machine power | About 5.5KW |
| 电源电压 | supply voltage | Three phase 380V/50HZ |
| 机身重量 | Weight | 1300KG |
1.用于opp、美纹纸、双面胶、高温胶带等有粘性材料复卷所需要长度之用.
2.收卷张力采用数显式张力，可全自动验算自动递增张力.
3.采用压花特弗龙作主传动机构，惰轮采用阳极处理铝轮.
4.放卷采用10KG磁粉刹车控制放卷张力可全自动验算自动递减张力.
5.放卷采用气涨轴，方便放卷半成品的卸料和装料.
6.自动记米功能，到达设定米数长度自动减速停机，减少材料浪费.
7.主机变频控制，传动部分采用链轮传动.
8.收卷形式为中心卷取收料.
1. Used for rewinding adhesive materials such as OPP, masking paper, double-sided tape, and high-temperature tape to the required length
2. The winding tension adopts a digital tension display, which can automatically verify and increase the tension
3. Embossed Teflon is used as the main transmission mechanism, and the idler wheel is made of anodized aluminum
4. The unwinding is controlled by 10KG magnetic powder brake, and the unwinding tension can be fully automatically verified and automatically decreased
5. The unwinding adopts an air expanding shaft, which facilitates the unloading and loading of semi-finished products
6. Automatic meter counting function, automatically slows down and stops when reaching the set meter length, reducing material waste
7. The host is controlled by frequency conversion, and the transmission part adopts chain wheel drive
8. The winding form is centered winding for material collection
