| Main technical parameters | ||
| 最大原料宽度 | Maximum raw material width | 1000mm/1300mm/1600mm |
| 最大原料直径 | Maximum raw material diameter | φ800mm |
| 最大收卷直径 | Maximum winding diameter | φ230mm (four axis exchange) |
| 最大收卷直径 | Maximum winding diameter | φ370mm (dual axis exchange) |
| 最小分条宽度 | Minimum stripe width | 12mm |
| 分条方式 | Splitting method | 3-hole straight knife |
| 机械最高速度 | Mechanical maximum speed | 180m-260m/minute |
| 纸管内径 | Inner diameter of paper tube | 3-inch core (φ76-76.5mm) |
| 使用气源 | air source | 6kw/cm² |
| 整机功率 | Whole machine power | About 5.5KW |
| 电源电压 | supply voltage | Three phase 380V/50HZ |
| 机身重量 | Weight of the airframe | 1600KG |
1.用于BOPP印刷胶带分切之用。
2.放卷张力采用全自动张力控制器，全自动验算自动递增张力。
3.智能7寸触摸屏及键式均可同时控制，操作简单。
4.不停机自动贴标；四轴自动交换不停机上下换取轴。
5.不停机换取轴；自动锁头装卸更便捷高效。
6.采用压花特弗龙作主传动机构，惰轮采用阳极处理铝轮。
7.放卷采用10KG磁粉刹车，自动张力控制。
8.分切刀架自动升降。
9.放卷采用气涨轴，方便放卷半成品的卸料和装料。
10.自动记米功能,到达设定米数长度自动减速停机,减少材料浪费.
11.主机自动变频控制，传动部分采用链轮传动.
12.移动罗拉缠绕式收边大卷废料.
1. Used for cutting BOPP printing tape.
2. The unwinding tension adopts a fully automatic tension controller, which automatically calculates and increases the tension.
3. The intelligent 7-inch touch screen and key type can be controlled simultaneously, with simple operation.
4. Automatic labeling without stopping the machine; Four axis automatic exchange without stopping, up and down exchange axis.
5. Exchange shafts without stopping the machine; Automatic lock head loading and unloading is more convenient and efficient.
6. Embossed Teflon is used as the main transmission mechanism, and the idler wheel is made of anodized aluminum.
7. The unwinding adopts 10KG magnetic powder brake and automatic tension control.
8. The slitting knife holder is automatically raised and lowered.
9. The unwinding adopts an air expanding shaft, which facilitates the unloading and loading of semi-finished products.
10. Automatic meter counting function, automatically slows down and stops when the set meter length is reached, reducing material waste.
11. The host adopts automatic frequency conversion control, and the transmission part adopts chain wheel drive.
12. Mobile roller winding edge trimming large roll waste.
